NEUTRIK BNC Cable Connector NBNC75BTU11X
The rearTWIST UHD BNC connectors are specifically designed for high resolution video signal transmissions. Due to the unique insulator and contact pin design, the connectors feature low return loss values for 4K and 8K signals.
Price
₹621.86
This feature is only available for variable products.
- This price is exclusive of GST and import duties.
- Estimated delivery date will be 6 to 12 days
Brand:
Neutrik
SKU:
NBNC75BTU11X
MPN:
NBNC75BTU11X
UPC/HSN:
85366990
Share
Menu
Features & Benefits
Optimized contact pin and insulator design for UHD-data transmissions
Proven rearTWIST technology
Swiss antraloy plating
Fully compatible with conventional BNC chassis connectors
Improved return loss values at high frequencies
Description
Technical Information
| Title | NBNC75BTU11X | |
| Connection Type | BNC 75 Ω | |
| Gender | male | |
| Cable O.D. | 7.3 mm | |
| Cable retention | > 30 N (center) | |
| Crimp size | 7.36 Hex crimp (shield) | |
| Crimp size (pin) | 1.07 crimp | |
| Insertion force | < 25 N | |
| Lifetime | > 1000 mating cycles | |
| Locking device | Bayonett | |
| Cable anchoring | Jacket crimping | |
| Temperature range | -30 °C to +85 °C | |
| Contact crimpability | Complies with IEC 60803 and IEC 60352-2 |
| Contact resistance | ≤ 3 mΩ (inner) | |
| Contact resistance | ≤ 2 mΩ (outer) | |
| Dielectric strength | 1.5 kVdc | |
| Impedance | 75 Ω | |
| Insulation resistance | > 5 GΩ | |
| Rated voltage | < 50 V | |
| VSWR | ≤1.06 / >30 dB up to 6 GHz ≤1.13 / >24 dB up to 12 GHz ≤1.22 / >20 dB up to 18 GHz |
|
| Contacts | Brass (CuZn35Pb2), 0.2 µm AuCo (center contact) | |
| Shell | Brass (CuZn39Pb3) | |
| Shell plating | Antraloy | |
| Insert | PP |
